Texas Instruments TMS320F28035PNTR: A Performance Benchmark in Real-Time Control

In real-time control scenarios such as industrial automation, renewable energy generation, and electric vehicles, microcontroller (MCU) performance directly determines system responsiveness and control precision. Texas Instruments' TMS320F28035PNTR, a flagship product in the C2000™ real-time control MCU family, has become a core control unit for industrial motor drives, photovoltaic (PV) inverters, and digital power supplies thanks to its 60MHz operating frequency, 128KB Flash memory, and highly integrated control peripherals.

Core Specifications and Technical Features
The TMS320F28035PNTR adopts an LQFP-80 package with an operating temperature range of -40°C to 105°C, meeting industrial-grade requirements. Key specifications are summarized below:

Parameter	Specification
CPU Frequency	60MHz (C28x core)
Memory	128KB Flash, 20KB SRAM
Analog Integration	12-bit ADC (16 channels), 2 analog comparators (with 10-bit internal reference)
PWM Modules	Enhanced ePWM (supports HRPWM high-resolution modulation)
Communication	UART, SPI, I2C, CAN 2.0B
Power Management	Internal regulator supports single 3.3V supply
Package/Pins	80-pin LQFP (12mm×12mm footprint, 0.5mm pitch)

A standout feature is the Control Law Accelerator (CLA), an independent 32-bit floating-point coprocessor that handles complex control algorithms (e.g., PID, FOC) in parallel, freeing the main CPU. This reduces system latency by over 50%. For example, in PV inverters, the CLA performs real-time maximum power point tracking (MPPT) calculations while the main CPU manages communication and protection logic.

Typical Applications
1. Industrial Motor Drives
In servo drive systems, the TMS320F28035PNTR generates high-precision PWM signals via ePWM modules. With HRPWM technology enabling 200kHz+ switching frequencies, motor noise and losses are significantly reduced. Its 16-channel 12-bit ADC synchronously samples current, voltage, and temperature signals with just 50ns sampling delay, meeting vector control (FOC) real-time requirements.

2. Photovoltaic Inverters
The integrated CAN 2.0B interface supports high-speed communication between inverters and monitoring systems, while analog comparators directly connect to overcurrent/overvoltage detection circuits, triggering hardware protection within <1μs. In a 10kW string inverter case study, the CLA-enabled dual-loop control (voltage outer loop + current inner loop) achieved 99.5% MPPT efficiency and 98.7% full-load efficiency.

3. Digital Power Supplies
For DC-DC converters, the enhanced capture module (eCAP) precisely measures inductor current ripple, enabling dynamic adjustments via PID algorithms. A 48V/12V bidirectional power supply design demonstrated that voltage recovery time after load transients improved from 200μs to 80μs (60% faster) using the TMS320F28035PNTR.

Frequently Asked Questions
Q1: How does the TMS320F28035PNTR ensure ADC sampling accuracy?
The ADC module supports hardware oversampling and averaging, boosting effective resolution to 14 bits. The VREFHI/VREFLO pins provide proportional reference voltages to eliminate power supply fluctuations. For optimal linearity, TI recommends connecting VREFHI to a 1.8V precision reference (e.g., REF3020).

Q2: How to resolve CAN bus Error-Passive mode lockup caused by vibrations?
When transient disconnections occur, reset CAN error counters via software:

Monitor CANES register flags (TXOK/RXOK).
Disable the CAN module (clear CCE bit) when counters approach 128.
Reinitialize CAN configuration and re-enable the module.
TI's application report SPRAA88 provides complete code examples.
Q3: Does the device support cold-start at low temperatures?
The industrial-grade temperature range (-40°C to 105°C) covers most applications. At -40°C, ensure supply voltage remains above 1.71V and allocate ≥2ms power-on reset time for internal oscillator calibration.

Conclusion
The TMS320F28035PNTR delivers a cost-effective real-time control solution through its high-performance CPU, dedicated control coprocessor, and integrated analog peripherals. Its code compatibility (supporting C28x family migration) and rich development tools (e.g., ControlSUITE software) accelerate time-to-market. Driven by Industry 4.0 and the renewable energy revolution, this device continues to empower technological innovation in smart manufacturing and green energy sectors.
