0Optoisolators - Logic Output
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Inputs-Side1/Side2 | Voltage-Isolation | CommonModeTransientImmunity(Min) | InputType | OutputType | Current-Output/Channel | DataRate | PropagationDelaytpLH/tpHL(Max) | Rise/FallTime(Typ) | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | Voltage-Supply | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
5962-0824203KUCOPTOISO 1.5KV 2CH OPN COLL 16SMD Broadcom Limited |
2,648 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
5962-9800102KPAOPTOISO 1.5KV 2CH OPEN COLL 8DIP Broadcom Limited |
3,138 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
|
5962-9800102KPCOPTOISO 1.5KV 2CH OPEN COLL 8DIP Broadcom Limited |
3,747 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
|
5962-9800102KYAOPTOISO 1.5KV 2CH OPEN COLL 8SMD Broadcom Limited |
3,321 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
|
5962-9800102KYCOPTOISO 1.5KV 2CH OPEN COLL 8SMD Broadcom Limited |
3,361 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
5962-9800102KZAOPTOISO 1.5KV OPEN COLL 8DIP GW Broadcom Limited |
2,844 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
5962-9800101KECOPTOISO 1.5KV 2CH OPEN COL 16DIP Broadcom Limited |
2,136 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.55V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
|
ACPL-563KLOPTOISO 1.5KV 2CH OPEN COLL 8DIP Broadcom Limited |
2,148 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
ACPL-563KL-100OPTOISO 1.5KV 2CH OPEN COLL 8SMD Broadcom Limited |
2,333 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
ACPL-563KL-200OPTOISO 1.5KV 2CH OPEN COLL 8DIP Broadcom Limited |
3,223 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
ACPL-563KL-300OPTOISO 1.5KV OPEN COLL 8DIP GW Broadcom Limited |
3,112 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
HCPL-663KOPTOISO 1.5KV 2CH OPN COL 20LCCC Broadcom Limited |
3,894 | - |
RFQ |
Datasheet |
Bulk | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
|
5962-0824202KPAOPTOISO 1.5KV 2CH OPEN COLL 8DIP Broadcom Limited |
2,133 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
5962-0824202KPCOPTOISO 1.5KV 2CH OPEN COLL 8DIP Broadcom Limited |
2,983 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
5962-0824202KXAOPTOISO 1.5KV OPEN COLL 8DIP GW Broadcom Limited |
2,516 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
5962-0824202KYAOPTOISO 1.5KV 2CH OPEN COLL 8SMD Broadcom Limited |
3,632 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
5962-0824202KYCOPTOISO 1.5KV 2CH OPEN COLL 8SMD Broadcom Limited |
2,612 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
5962-9800103K2AOPTOISO 1.5KV 2CH OPN COL 20LCCC Broadcom Limited |
2,162 | - |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
|
HCPL-540KOPTOISO 1.5KV TRI-STATE 8DIP Broadcom Limited |
2,977 | - |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | -55°C ~ 125°C | Through Hole |
|
|
HCPL-540K-100OPTOISO 1.5KV TRI-STATE 8SMD Broadcom Limited |
2,396 | - |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | -55°C ~ 125°C | Surface Mount |
